WhatsApp Cloud API Setup Guide and Integration Costs

A complete guide comparing official WhatsApp Cloud API vs Baileys, Meta integration costs, step-by-step setup, and channel configurations.

WhatsApp Cloud API Setup Guide and Integration Costs

Channels: official vs unofficial, and what things actually cost

WhatsApp: two different integrations exist in this codebase

whatsappCloudHandler.js (official) whatsappWorker.js + whatsappManager.js (baileys)
What it is Meta's own Cloud API Reverse-engineered WhatsApp Web protocol
Approved by Meta? Yes No — against WhatsApp's Terms of Service
Ban risk None (it's the real API) Real — numbers get banned, especially once you're sending commercial volume
Setup Meta Developer account, no phone needed for testing Scan a QR code with your own phone
Cost Free for replying to customers (see below) Free, but you're paying with risk instead of money

For a marketplace/commercial product, use the Cloud API. It's what
docs/DEPLOYMENT.md and this guide both assume from here. The baileys
files are still in the repo in case you want them for a personal/low-
stakes project, but don't ship a paying product on top of them.

What this actually costs you

  • WhatsApp Cloud API access itself: free. No subscription fee to Meta.
  • Replying to a customer within 24 hours of their message ("service
    conversation"): free.
    This is your exact use case — customer messages
    you, bot replies. You will not be charged for this.
  • You only pay if you message a customer first with a marketing or
    utility template (e.g. a promotional broadcast) — a few cents per
    conversation, varies by country. Skip this entirely for now; nothing
    in the current build sends unprompted outbound messages.
  • You do not need a paid middleman (BSP) like Twilio/360dialog/Wati.
    Meta's Cloud API can be called directly — the whatsappCloudHandler.js
    code in this repo does exactly that, no markup, no extra subscription.
  • Messenger Platform: free. Meta doesn't charge per-conversation for
    Messenger the way it does for WhatsApp.

Conversions API, Pixel, Open Graph — do you need these now?

Short answer: skip the first two for now, Open Graph is already done.

  • Meta Pixel / Conversions API — these track website visitors and ad
    performance, for when you're running Facebook/Instagram ads. They have
    nothing to do with the chatbot working. Add them later if/when you
    actually start advertising; they add setup complexity and API review
    steps you don't need for a working product today.
  • Open Graph — just the meta tags that make your link look right
    when shared on WhatsApp/Facebook/Twitter. Already added to
    frontend/index.html, using docs/marketing-banner.png as the
    preview image. Nothing left to do here.

Setting up WhatsApp Cloud API (free, test mode — no business verification needed yet)

  1. Go to developers.facebook.com, log
    in with your own Facebook account, create a Meta Developer account
    (free).
  2. My Apps → Create App → use case "Other" → type "Business."
  3. In your new app's dashboard, Add Product → WhatsApp → Set up.
  4. Meta gives you a free test phone number and a temporary access
    token
    immediately — no business verification needed yet. You can
    add up to 5 of your own personal numbers as verified recipients and
    send/receive real messages right away.
  5. Note down: the Phone Number ID (shown on the API Setup page) and
    the access token. These go into this platform's dashboard under
    Channels → WhatsApp (once that credential form is added — see below).
  6. Configure the webhook: still on the WhatsApp product page →
    Configuration → Webhook → Edit. Set:
    • Callback URL: https://api.yourdomain.com/api/webhooks/whatsapp
    • Verify token: any string you make up (put the same string in
      this platform's Channels page so the two match)
    • Subscribe to the messages field.
  7. Meta will call your callback URL once with a GET request to confirm
    it — this repo's webhook route already handles that handshake
    (whatsappCloudHandler.verifyWebhook).

This all works with zero business verification and zero cost, good
enough for your live preview and testing with your own phone. Business
verification (needed to message the general public beyond your 5 test
numbers) is a separate, still-free step you do later when you're ready
to launch for real.

Setting up Messenger (also free)

  1. Same Meta app → Add Product → Messenger → Set up.
  2. Connect a Facebook Page you admin (create a free one if needed).
  3. Generate a Page Access Token on the Messenger product page.
  4. Webhook: Callback URL https://api.yourdomain.com/api/webhooks/messenger,
    same verify-token idea as WhatsApp, subscribe to the messages field.
  5. While the app is in development mode, only Page admins/testers can
    message the bot — fine for your live preview.

What's already built vs. what still needs the dashboard form

backend/src/channels/whatsapp/whatsappCloudHandler.js and
.../messenger/messengerHandler.js are complete and tested against a
real database (see scripts/test-channel-creds.js-style checks). The
API endpoint to save credentials exists too:
POST /api/channels/:channel/credentials with { accessToken, phoneNumberId | pageId, webhookVerifyToken }. What's left is a small
form on the Channels page in the dashboard so you don't have to call
that endpoint by hand with curl/Postman while testing — ask if you'd
like that added next.
